Saga Orchestration vs Choreography Selection Criteria

Introduction

In organizations that deal with distributed transactions, the failure model itself changes the moment the Saga pattern is introduced. The problem is that Orchestration and Choreography are often chosen based on technical preference. This article presents practical criteria for choosing between the two models based on team structure, frequency of change, and failure response methods.

Saga Orchestration vs Choreography 선택 기준 커버 — Wikimedia Commons 기반 무료 이미지

Problem definition

If the Saga structure is chosen incorrectly, the recovery time in the exception scenario increases dramatically even though it works in the normal scenario.

Domain events are expanded indiscriminately, making it impossible to track event flow.
Compensation transactions are scattered by service, making them highly likely to be missed in the event of a failure.
MTTR increases as the operations team does not have full flow visibility.

The selection criteria are simple. If the flow is complex and policy changes are frequent, Orchestration is advantageous, and if service independence and loose coupling are more important, Choreography is advantageous.

Key concepts

perspective	Design criteria	Verification points
central control	Orchestrator Single Flow Management	Point of Failure Tracking Difficulty
distributed autonomy	event-based state transition	Service Independent Deployment Frequency
Compensation Strategy	Explicit compensation definition	Missing/duplicate compensation rate
Observability	Saga instance-level tracking	Average time to recovery

You can also select by domain. In practice, a mixed application of Orchestration for flows with complex rules such as payment/settlement and Choreography for notification/analysis pipelines is often used.

Code example 1: Orchestrator state transition

type SagaStep = "reserve" | "pay" | "ship";

export class OrderSagaOrchestrator {
  async execute(orderId: string) {
    try {
      await this.reserveInventory(orderId);
      await this.capturePayment(orderId);
      await this.requestShipping(orderId);
      return { status: "COMPLETED" };
    } catch (error) {
      await this.compensate(orderId);
      return { status: "COMPENSATED", reason: String(error) };
    }
  }

  private async compensate(orderId: string) {
    await this.refundPayment(orderId);
    await this.releaseInventory(orderId);
  }
}

Code example 2: Choreography event consumer

export async function onPaymentCaptured(event: { orderId: string; amount: number }) {
  await publish("shipping.requested", { orderId: event.orderId });
}

export async function onShippingFailed(event: { orderId: string }) {
  await publish("payment.refund.requested", { orderId: event.orderId });
}

export async function onPaymentRefunded(event: { orderId: string }) {
  await publish("inventory.release.requested", { orderId: event.orderId });
}

Architecture flow

Mermaid diagram rendering...

Clean Architecture Layer Structure

If Saga is a use case in the application layer and each service call is separated into an adapter layer, it becomes easier to test the compensation logic.

Layer	responsibility	How to apply
Entities	Order Status Model	OrderAggregate
Use Cases	Saga flow control	ExecuteOrderSaga
Interface Adapters	Payment/Inventory port	PaymentGatewayAdapter
Frameworks	Message Broker/DB	Kafka, PostgreSQL

Infrastructure diagram
