Queue Backpressure Control Pattern

Introduction

The real problem with queue-based asynchronous processing is not throughput but backpressure. When consumers slow down or go down, queue backlog builds up quickly, eventually spreading to overall system delays and timeouts. This article organizes patterns that deal with backpressure at the design level in a practical manner.

Queue Backpressure 제어 패턴 커버 — Wikimedia Commons 기반 무료 이미지

Problem definition

Pipelines that do not take backpressure into account collapse unpredictably during peak traffic.

There is no producer transmission speed limit, so the queue length increases infinitely.
Because the consumer retry policy is aggressive, the number of identical messages increases explosively.
There is no priority policy, so important tasks wait for a long time.

The key is to control inputs and isolate failures. Rate limit, retry budget, and dead letter separation must be designed simultaneously.

Key concepts

perspective	Design criteria	Verification points
input control	producer rate limit	Queue backlog growth rate
Consumption Control	consumer concurrency limits	Job success rate
Retry	exponential backoff + budget	Duplicate processing rate
quarantine	DLQ + priority queue	Core task latency

Backpressure is an application policy, not an infrastructure option. You must decide in advance which tasks to give up and what to keep in case of processing failure.

Code example 1: Retry budget control

export function nextRetryDelay(attempt: number, maxAttempts: number) {
  if (attempt >= maxAttempts) return null;

  const base = 500;
  const delay = Math.min(base * 2 ** attempt, 30_000);
  const jitter = Math.floor(Math.random() * 300);
  return delay + jitter;
}

export function shouldMoveToDlq(attempt: number, maxAttempts: number) {
  return attempt >= maxAttempts;
}

Code example 2: Queue consumer concurrency limits

const MAX_IN_FLIGHT = 20;
let inFlight = 0;

export async function consume(message: QueueMessage) {
  if (inFlight >= MAX_IN_FLIGHT) {
    await message.nack({ requeue: true, delayMs: 300 });
    return;
  }

  inFlight += 1;
  try {
    await processMessage(message);
    await message.ack();
  } finally {
    inFlight -= 1;
  }
}

Architecture flow

Mermaid diagram rendering...

Clean Architecture Layer Structure

By managing the backpressure policy as an application layer use case and separating the message broker implementation into the infrastructure layer, testing and operational tuning become easier.

Layer	responsibility	How to apply
Entities	task state model	Job, RetryPolicy
Use Cases	Processing/Retry Policy	ProcessQueueJob
Interface Adapters	Queue Consumer/Producer	KafkaAdapter
Frameworks	Broker, Metrics	Kafka, Prometheus

Infrastructure diagram
