gRPC + REST Gateway parallel strategy

Introduction

To switch internal communication to gRPC while maintaining the existing REST API, contract management is more important than performance. Introducing a gateway ensures external compatibility, but if schema version and error code mapping is loose, debugging costs increase rapidly. This article summarizes the migration steps, team boundaries, and observation points for running REST and gRPC in parallel.

gRPC + REST Gateway 병행 전략 커버 — Wikimedia Commons 기반 무료 이미지

Problem definition

The reason the parallel strategy fails is because it treats the middle layer as temporary code. The following items must be fixed first:

Proto changes and OpenAPI changes are separated, causing discrepancies between documentation and actual operation.
Client failures increase as gRPC status codes are not consistently converted to HTTP status.
There is no upstream metadata in the gateway log, so it is difficult to track delay time for each section.

In the previous stages, regression control takes precedence over transition speed. Contract testing and sample traffic replays should be included as mandatory procedures.

Key concepts

perspective	Design criteria	Verification points
Contract Synchronization	Manage Proto from a single source of truth	Whether OpenAPI is automatically created
error mapping	Standardize bidirectional mapping between gRPC status and HTTP status	Client Retry Error Rate
Performance	split timeout budget at gateway	p95 latency increase/decrease
Observation	trace context propagation	Tracking the cause of delay by section

The period of combining REST and gRPC is the period of highest architectural risk. The list of functional unit conversions and withdrawal criteria must be documented together.

Code example 1: gRPC status code HTTP mapping

import { status } from "@grpc/grpc-js";

export function grpcToHttp(code: status): number {
  switch (code) {
    case status.OK:
      return 200;
    case status.INVALID_ARGUMENT:
      return 400;
    case status.UNAUTHENTICATED:
      return 401;
    case status.PERMISSION_DENIED:
      return 403;
    case status.NOT_FOUND:
      return 404;
    case status.ALREADY_EXISTS:
      return 409;
    default:
      return 500;
  }
}

Code example 2: Gateway handler

export async function getUserProfile(req: Request) {
  const id = new URL(req.url).searchParams.get("id");
  if (!id) return Response.json({ message: "id required" }, { status: 400 });

  try {
    const result = await grpcClient.GetUser({ id }, { deadline: Date.now() + 300 });
    return Response.json(result, { status: 200 });
  } catch (error) {
    const code = (error as { code?: number }).code;
    return Response.json({ message: "upstream error" }, { status: grpcToHttp(code ?? 13) });
  }
}

Architecture flow

Mermaid diagram rendering...

Clean Architecture Layer Structure

Since the boundaries are likely to become blurred during the parallel period, it is safe to fix the gateway as an adapter layer based on Clean Architecture.

Layer	responsibility	How to apply
Entities	request/response domain model	UserProfile, OrderSummary
Use Cases	Protocol independent business logic	GetUserProfileUseCase
Interface Adapters	REST, gRPC transformation	GatewayController, GrpcPresenter
Frameworks	Next.js Route/Env	HTTP server, gRPC client

Infrastructure diagram
